Product Overview

Description

Product Specifications:

Capacity: 1.92kWh

Rated Voltage: 19.2V⎓

Max. Charging Power: 1050W

Max. Discharging Power: 1200W

Cell Chemistry & Cycle Life: LFP, 6,000 cycles to 70% capacity

MPPT (PV Input Power & Voltage): 4 MPPT, 2000W (500W × 4), 15V–60V⎓

Max. Input Voltage: 60V⎓

Max. Input Current: 4 × 14A

Max. Input Short Circuit Current: 4 × 20A

Rated AC Output Power (Grid Terminal): 800W

Rated Voltage and Frequency (Grid Terminal): 120V~, 60Hz

Rated Output Current (Grid Terminal): 6.67A

Max. Input (Grid Terminal): 1200W (10A)

Battery Self-Heating: Low-Temperature Charging Activation (≤5°C)

Ingress Protection Rating: NEMA 4

Operating Temperature: -20°C to 55°C

Discharge Temperature: -20°C to 50°C (-4°F to 122°F)

Dimensions: 255 × 284 × 458mm (10.0 × 11.2 × 18.0in)

Communication: Wi-Fi, Bluetooth

Acoustic Noise: <30dB

Net Weight: 23.1 ± 0.5kg

Build-in Features: Output Overcurrent Protection, Output Overvoltage Protection, Anti-islanding Protection

Warranty Coverage

5 Years Warranty | Human Error not Covered
